Major Facilities
SLITTER
Coil Insertion
SLITTING
SLITTING in Progress
RECOILING
EMBO
UNCOILING
EMBO
EMBO
RECOILING
SHEAR
Coil Loading
SHEAR
Inspection
Packing
FORMING
FORMING 1
FORMING 2
FORMING 3
FORMING 4
Production Facilities (capacity)
| FACILITY | Avg.thickness | Avg.width | Avg.length | Avg.speed | TIME/1day | Rate of operation | Output/1day | Output/1month |
|---|---|---|---|---|---|---|---|---|
| Large ROTARY SHEAR | 0.6 | 800 | 2500 | 55M/min | 10H/1 | 70% | 87T | 2100T |
| Medium FLYING SHEAR | 0.6 | 700 | 1200 | 45M/min | 10H/1 | 70% | 60T | 1500T |
| MINI SHEAR Ⅰ | 0.6 | 500 | 1200 | 30M/min | 10H/1 | 70% | 30T | 750T |
| MINI SHEAR Ⅱ | 0.6 | 500 | 1200 | 30M/min | 10H/1 | 70% | 30T | 750T |
| Large SLITTER | 0.6 | 1219 | MAX | 120M/min | 10H/1 | 80% | 320T | 8000T |
| MINI SLITTER | 0.6 | 600 | MAX | 60M/min | 10H/1 | 80% | 80T | 2000T |
| BOTH EMBOSS LINE | 0.6 | MAX | 2500 | 100M/min | 10H/1 | 80% | 120T | 3000T |
- 1 SHIFT SHEARING capacity: Monthly average total output 5,100T
- 1 SHIFT SLITTER capacity: Monthly average total output 10,000T (* LINE operated flexibly with 2 SHIFTS depending on production volume)
